EFV-8 Club Forum / General Ford Discussion / Is this a '46-'48 engine?

Reply to Discussion | New Discussion

<< previous || next >>

Posted By

Discussion Topic: Is this a '46-'48 engine? -- page: 1 2

Flatbob

09-20-2012 @ 10:07 PM

reply profile send p.m.

Member
Posts: 437
Joined: Oct 2009

Heads are marked 59AB and I believe that was for the years '46-'48. What looks unusual to me is the oil pan and the twin shift levers; would this engine be out of a truck? Tried to post pics.

40 Coupe

09-21-2012 @ 3:50 AM

reply profile send p.m.

Senior
Posts: 1676
Joined: Oct 2009

because of the shift levers it appears the transmission is truck. It is possible the 59AB could have been used in a truck and the trans and oil pan bolted to it. I believe it is also possible the 59AB heads may have been used on a truck engine.

1932BB

09-21-2012 @ 6:11 AM

reply profile send p.m.

New Member
Posts: 104
Joined: Oct 2009

So what's with the twin shift levers? Can anyone shed some light on this? Doesn't look like a splitter!

ford38v8

09-21-2012 @ 7:11 AM

reply profile send p.m.

Senior
Posts: 2762
Joined: Oct 2009

The engine is not a 59. No bell housing on the block, and not visible in the picture, but should have the LoadaMatic distributor. Heads are interchangeable with the 59 series heads. Might be an 8RT.

Alan

supereal

09-21-2012 @ 10:35 AM

reply profile send p.m.

Senior
Posts: 6819
Joined: Oct 2009

The transmission is similar to the type used in marine applications which required only a forward-reverse gear. A photo of the front of the engine would be helpful in determining the model of engine. As noted, the clutch housing appears to be of the later 8BA type, a sort of ring that connects the block to the transmission. Marine and commercial power units often had unusual configurations not seen in either cars or trucks.

Flatbob

09-21-2012 @ 11:56 AM

reply profile send p.m.

Member
Posts: 437
Joined: Oct 2009

Here's another photo

deuce_roadster

09-21-2012 @ 1:09 PM

reply profile send p.m.

Member
Posts: 284
Joined: Oct 2009

Looks like a cast on bell housing to me, I don't see any bolts holding an 8ba one on there.
The pic from the front makes me think it is a 59 series block. Water pumps don't have that extra part sticking up, angle of block down from head surface, etc. I think you are right 46-8

That is one bizarre shift lever deal though. How about a picture of the top of the trans where the lever(s) go in?

ford38v8

09-21-2012 @ 2:46 PM

reply profile send p.m.

Senior
Posts: 2762
Joined: Oct 2009

Appears to be a water cooled oil pan. Look at the front inlets, one with a hose, and in the first picture the outlet pipe and attached hose, and the stack pipe? Open drive and a speedo turtle. Unusual creature!

Alan

supereal

09-21-2012 @ 3:23 PM

reply profile send p.m.

Senior
Posts: 6819
Joined: Oct 2009

It sure looks like a later clutch housing, but it is so cruddy, it is hard to be sure. The distributor is definitely a 46 to 48 type. If it isn't a marine adaptation, it could be an engine used on a pump or a sawmill, etc. Lots of these engines were used for such purposes. One thing is sure: it looks like it is scr*p.

deuce_roadster

09-21-2012 @ 4:16 PM

reply profile send p.m.

Member
Posts: 284
Joined: Oct 2009

Flatbob, thanks for sending pictures of this thing! It is fun seeing oddball stuff like this. I wonder if someone built a Rube Goldberg deal to watercool the pan? Didn't some truck pans have a part that could unbolt so you could change the clutch without removing the whole pan? Maybe they started with something like that. If you double click the pictures and enlarge them you can see detail better. There is something cast where a "59" would be but can't quite make it out. Maybe it was to run a big saw or water pump like Super said --some stationary use. Maybe it was from Alaska and they pumped HOT water through that setup to keep the oil from getting too thick!! Ha it would be fun to know the whole story on that thing.

<< previous || next >>

PAGE: 1 2
