EFV-8 Club Forum / General Ford Discussion / Is this a '46-'48 engine?

Reply to Discussion | New Discussion

<< previous || next >>

Posted By

Discussion Topic: Is this a '46-'48 engine? -- page: 1 2

TomO

09-23-2012 @ 5:44 PM

reply profile send p.m.

Senior
Posts: 7253
Joined: Oct 2009

The 59 on the top of the bell housing shows up real plain on photo 3. It is a 46-48 engine, with a modified oil pan and a mystery transmission. I think Supereal is right with the marine application.

Tom

ford38v8

09-22-2012 @ 7:03 PM

reply profile send p.m.

Senior
Posts: 2762
Joined: Oct 2009

42Merc, I think we've all expanded the pictures, and don't see what you see.

Alan

40guy

09-22-2012 @ 4:18 PM

reply profile send p.m.

Member
Posts: 270
Joined: Oct 2009

4-Wheel drive trans?

42merc

09-22-2012 @ 4:06 PM

reply profile send p.m.

New Member
Posts: 126
Joined: Dec 2010

Expanding the first photo you can see 59 on the top of the bellhousing and 18-??on the trans. Trans & rear mount looks like 35-36 to Me. The two sticks & rear coupler I don't recognize.
The fan & generator bracket are narrow belt 8ba.

This message was edited by 42merc on 9-22-12 @ 4:10 PM

ford38v8

09-21-2012 @ 9:13 PM

reply profile send p.m.

Senior
Posts: 2762
Joined: Oct 2009

The last picture presents another element: The fan with the big pulley... If that mounts somehow on this engine, I'd think a stationary high revving engine, with a very high mounted radiator!

Alan

Stroker

09-21-2012 @ 4:46 PM

reply profile send p.m.

Senior
Posts: 1460
Joined: Oct 2009

1932BB: I'm with you on the weird trans shift tower. I've dealt with "Brownies", Eaton
2-Speeds, etc. but I've never seen a shift tower that had two sticks. It's obviously a
38-48 block, but beyond that, I can't add a lot. If it was a marine application, I'd think that it would have water-cooled exhaust manifolds. I'll vote with Super though, that its' highest and best use may be the smelter (so it can come back to us as Chinese
water pumps).

Flatbob

09-21-2012 @ 4:37 PM

reply profile send p.m.

Member
Posts: 437
Joined: Oct 2009

Another view

Flatbob

09-21-2012 @ 4:30 PM

reply profile send p.m.

Member
Posts: 437
Joined: Oct 2009

Am wondering if this engine was used in some sort of mining application. The mountains surrounding Las Vegas are filled with old abandoned mines.

deuce_roadster

09-21-2012 @ 4:16 PM

reply profile send p.m.

Member
Posts: 284
Joined: Oct 2009

Flatbob, thanks for sending pictures of this thing! It is fun seeing oddball stuff like this. I wonder if someone built a Rube Goldberg deal to watercool the pan? Didn't some truck pans have a part that could unbolt so you could change the clutch without removing the whole pan? Maybe they started with something like that. If you double click the pictures and enlarge them you can see detail better. There is something cast where a "59" would be but can't quite make it out. Maybe it was to run a big saw or water pump like Super said --some stationary use. Maybe it was from Alaska and they pumped HOT water through that setup to keep the oil from getting too thick!! Ha it would be fun to know the whole story on that thing.

supereal

09-21-2012 @ 3:23 PM

reply profile send p.m.

Senior
Posts: 6819
Joined: Oct 2009

It sure looks like a later clutch housing, but it is so cruddy, it is hard to be sure. The distributor is definitely a 46 to 48 type. If it isn't a marine adaptation, it could be an engine used on a pump or a sawmill, etc. Lots of these engines were used for such purposes. One thing is sure: it looks like it is scr*p.

<< previous || next >>

PAGE: 1 2
