EFV-8 Club Forum / General Ford Discussion / Eratic starter

Reply to Discussion | New Discussion

<< previous || next >>

Posted By

Discussion Topic: Eratic starter -- page: 1 2

voced

08-14-2017 @ 5:01 AM

reply profile send p.m.

Member
Posts: 86
Joined: Oct 2009

My 36 sometimes acts like a low battery when you push the starter and other times it turns over like a new one. I have changed the starter switch, cables look like new and new 6 volt starter. I even put on extra grounds from frame to engine. Not sure where to go from here. Help appreciated. Jerry

sarahcecelia

08-14-2017 @ 6:05 AM

reply profile send p.m.

Senior
Posts: 1183
Joined: Mar 2013

Sounds like a bad (dirty or loose) connection to me. clean all connections with 400 sandpaper and ensure that they are tight and clean.

Regards, Steve Lee

sarahcecelia

08-14-2017 @ 6:26 AM

reply profile send p.m.

Senior
Posts: 1183
Joined: Mar 2013

I would also think maybe the solenoid is bad. If it is it would, or could, operate erraticly. It has a set of contacts in it that take the full volts and amps, and those contacts may be badly burned!!

Regards, Steve Lee

voced

08-14-2017 @ 4:48 PM

reply profile send p.m.

Member
Posts: 86
Joined: Oct 2009

It doesn't have a solenoid, it is the foot push starter switch. I also cleaned all the connections. I am thinking about putting on new cables, even those the ones that are on there look like new. Or if it could be the floor push starter switch. I put on a repo one from MAC.
Thanks,
Jerry

pauls39coupe

08-14-2017 @ 7:00 PM

reply profile send p.m.

Member
Posts: 205
Joined: Jul 2014

If you are real carful you can take your floor mounted starter switch apart and clean and polish the contact surfaces. I would also have a load test done on the battery to see if it is OK.
Paul

voced

08-15-2017 @ 4:18 AM

reply profile send p.m.

Member
Posts: 86
Joined: Oct 2009

Thanks guy's, I will give your idea's a try. It is embarrassing to be at a car show with this beautiful Cabriolet and it sometimes acts like it won't start. Otherwise it runs like a new one.
Jerry

len47merc

08-15-2017 @ 4:23 AM

reply profile send p.m.

Senior
Posts: 1165
Joined: Oct 2013

Beautiful!

Steve

TomO

08-15-2017 @ 6:16 AM

reply profile send p.m.

Senior
Posts: 7250
Joined: Oct 2009

Jerry, your 36 Cabriolet looks great.

When the cables or switch are corroded they can fail intermittently, but will always have a higher resistance than good ones. To check out the cables and the switch, do a voltage drop test.

To get a good connection in the following tests, clean the battery posts and cable openings before the tests.

Connect a voltmeter black or COM lead to the battery post and the red or + lead to the terminal on the starter.

Crank the engine with the ignition off and check the voltage reading. It should be 0.3 Volts or less.

If it is 0.3 V or less, your problem is not in the cables or switch. If it is higher, move the red lead to the next connection toward the battery, which should be the output of the starter switch.

The reading should now be 0.2 V or less, if it is, replace the cable, if it is higher, go to the other side of the starter switch and repeat the test.

The reading should now be 0.1 v or less. If it is the starter switch is the failing component. If it is higher, the battery cable is the culprit.

To check the grounding of the starter, connect the red lead to the + terminal of the battery and the black lead to the case of the starter. Crank the engine with the ignition off and read the meter. The reading should be 0.1V or lower.

Other things that can cause this problem are bad battery disconnect switch, weak brush springs, worn rear bushing in the starter motor and worn ignition rotor.

Tom

trjford8

08-15-2017 @ 12:16 PM

reply profile send p.m.

Senior
Posts: 4214
Joined: Oct 2009

Look around for a new old stock or new old stock replacement switch. In the last few years going on tours,I have seen more than one of the repo starter switches fail. As others have said check everything else first, but my guess would be the switch.

sarahcecelia

08-16-2017 @ 12:51 PM

reply profile send p.m.

Senior
Posts: 1183
Joined: Mar 2013

That "Foot push" is a solenoid!

Regards, Steve Lee
